High Output Water Ring Pelletizer Machine SIEMENS Motor Brand 500-800kg/H

Short Description:

Detailed Product Description Screw Design: Twin Screw Extruder Application: PP PE + 80% Caco3 Warranty: One Year Lead Time: 45 Days After Deposit L/D: 48:1 Gearbox: 600rpm Motor: 160kw Capacity: 500-800kg/h LLDPE PP PE Water Ring Plastic Granulator Machine Twin Screw Pellet Machine Water Ring Pelletizer Application: 1. PE, Eva etc + Caco3, talk, Tio92, filling modification and carbon black etc. 2. LDPE, HDPE, LLDPE,MDPE, drivepipe, insulation material, crosslinking material, ...

Send email to us Download as PDF

Product Detail

Product Tags

Detailed Product Description

Screw Design:	Twin Screw Extruder	Application:	PP PE + 80% Caco3
Warranty:	One Year	Lead Time:	45 Days After Deposit
L/D:	48:1	Gearbox:	600rpm
Motor:	160kw	Capacity:	500-800kg/h

LLDPE PP PE Water Ring Plastic Granulator Machine Twin Screw Pellet Machine

Water Ring Pelletizer Application:

1. PE, Eva etc + Caco3, talk, Tio92, filling modification and carbon black etc.

2. LDPE, HDPE, LLDPE,MDPE, drivepipe, insulation material, crosslinking material, cable coating material, thermal contraction pipe material etc.

3. PPR pipe compounds, PE crosslinking tube material, TPR, TPU thermoplastic elastomer, EVA and hot melt adhesive etc.

4. PE, ABS, PS, EVA masterbatch etc.

5. ABS, EVA flaming retarding masterbatch etc.

6. PE, PP, PS filling and biodegradable masterbatch, etc.

Quick details of sjsl36 water ring pelletizer

Screw diameter:71mm

Screw material:W6Mo5Cr4V2

Barrel diameter:71.8mm

Barrel material:W6Mo5Cr4V2

Motor power:160kw

Motor brand:SIEMENS

L/D:48:1

Output:500-800kg/h

Transmission gear: Parallel tri-axial structure is combination of reduction and matrix. The gear is made of high quality alloy (20CrNi2Mo). It had been treated by cementation heat process, the precision grade can reach6th. It guarantees the tooth surface is high speed, overloading, low noise and high torque.

Drive bearing: The brand of axletree: NSK.

Lubrication: Gear bearings in the gear box will be of oil immersed. There is hydraulic lubrication in the gear engagement and gear bearings.

Cooling: Lubricated cooling adopts shell and tube cooler and circulated water cooling method.

Main parts and technical parameters

No.	Contents	Unit	Quantity	Marks
1	Twin screw extrusion system	set	1
1.1	Feeding system	set	1	1.5kw
1.2	SJ-75 Twin screw extruder	set	1	110kw, 44:1
13	Vacuum venting system	set	1	2.2kw
1.4	Water cycling system	set	1	0.55kw
1.5	Automatic screen changer	set	1	1.5kw
2	Electric cabinet	set	1
3	Water-ring auxiliary system	set	1
3.1	Water-ring die head	set	1
3.2	Face cutter with guide rail	set	1	1.5KW
3.3	Cutter cover	set	1
3.4	Centrifugal dehydrator	set	1	5.5KW
3.5	Vibrating sieve	set	1	0.4KW
3.6	Storage bin	set	1
4	Documents	set	1

Main Technical Details of Various Water Ring Pelletizer Models

Model type	Series	Barrel Diameter (mm)	Screw Diameter (mm)	Screw L/D	screw speed n(r/min)	Main motor power(Kw)	Screw torque T(N.m)	Torque rating (T/A³)	Typical production capacity (kg/h)
SJSL20	A/B	22	21.7	32-44	500/600	4/5.5kw	30/30
SJSL-36	A/B/C/D	36	35.6	32-48	400/600	11/15/18.5/22	125-225	4.6-8.3	30-120
SJSL-51	A/B/C/D	51	50.5	32-52	500/600	45/55/75/90	405-680	5.1-8.5	120-400
SJSL-65	A/B/C/D	63	62.4	32-64	500/600	75/90/110/132	680-1200	4.8-8.5	180-750
SJSL-75	A/B/C/D	72	71	32-64	500/600	110/132/160/250	995-1890	4.6-8.7	300-1200
SJSL-95	A/B/C/D	94	93	32-64	500/600	250/315/450/550	2260-4510	4.7-8.7	700-2500
SJSL-135	A/B/C/D	135	33	32-48	400/500	550/750/900/1200	6200-10800	4.4-7.7	1550-6500
